38.
CYMBAL
SHAPE
GRINDING WHEEL
钹型砂轮
1.The common reinforced cutting wheels can be
used of cutting or grooving of many different kinds of steel pipes, angle
steel, channel steel and round steel. They are no doubt the indispensable
tools for mechanical processing.
2.Reinforced cutting wheels are
special cutting tools which can cut 18-32mm “V” high manganese steel and other
harder section steels, showing high efficiency and
reliability.
USAGE:
Install
it in the angle grinder to grind freely. It is widely used to grind weld seam,
Welding
spot, burnish casting burrs, flash, and to repair defect in metal surface in
cars. ships,
mechanic
manufacturing metallurgy, chemical industry and so on.
To
improve the strength of emery wheels strength, we add a kind of resin twines in
the wheels, and they have high
tensile strength, shock strength and bending strength. Its speed can reach to
80m/s, and have the characteristics of high efficiency and safety.
They
have been inserted metal rings in the inner holes besides fiber grid cloth which
are made of special fiber reinforced composites. The following are wheels
specifications:
|
ART.
NO.
|
Out
diameter x thickness x inner diameter
|
Outer
packing
|
volume
|
MAX.
SPEED
|
|
INCHES
|
METRIC
(mm)
|
PCS
/ ctn
|
GW
(Kg)
|
NW
(Kg)
|
Length
x Width x Height
|
4300m/min
|
4800m/min
|
|
lcme38420601
|
4x1/8x5/8
|
100x3x16
|
400
|
22.5
|
22
|
42x22x23
|
13700R.P.M
|
15200R.P.M
|
|
lcme38270602
|
4x5/32x5/8
|
100x4x16
|
300
|
22.5
|
22
|
41.5x22x2
|
13700R.P.M
|
15200R.P.M
|
|
lcme38270603
|
4x3/16x5/8
|
100x5x16
|
250
|
22.5
|
22
|
40x22x23
|
13700R.P.M
|
15200R.P.M
|
|
lcme38270604
|
4x1/4x5/8
|
100x6x16
|
200
|
22.5
|
22
|
40x22x23
|
13700R.P.M
|
15200R.P.M
|
|
lcme38420605
|
41/2x1/8x7/8
|
115x3x22.2
|
200
|
13.5
|
13
|
40x25x13
|
11900R.P.M
|
13300R.P.M
|
|
lcme38270606
|
41/2x1/4x7/8
|
115x6x22.2
|
100
|
13.5
|
13
|
38x25x13
|
11900R.P.M
|
13300R.P.M
|
|
lcme38420607
|
5x1/8x7/8
|
125x3x22.2
|
200
|
17.5
|
17
|
40x27x14
|
11000R.P.M
|
12200R.P.M
|
|
lcme38270608
|
5x1/4x7/8
|
125x6x22.2
|
100
|
17.5
|
17
|
40x27x14
|
11000R.P.M
|
12200R.P.M
|
|
lcme38420609
|
6x1/8x7/8
|
150x3x22.2
|
200
|
23.5
|
23
|
40x32x17
|
9100R.P.M
|
10200R.P.M
|
|
lcme38270610
|
6x1/4x7/8
|
150x6x22.2
|
100
|
24.5
|
24
|
40x32x17
|
9100R.P.M
|
10200R.P.M
|
|
lcme38420611
|
7x1/8x7/8
|
180x3x22.2
|
200
|
32.5
|
32
|
40x20x38
|
7600R.P.M
|
8500R.P.M
|
|
lcme38270612
|
7x1/4x7/8
|
180x6x22.2
|
100
|
33.5
|
33
|
40x20x38
|
7600R.P.M
|
8500R.P.M
|
|
lcme38270613
|
7x5/6x7/8
|
180x8x22.2
|
80
|
33.5
|
33
|
40x20x38
|
7600R.P.M
|
8500R.P.M
|
|
lcme38420614
|
9x1/8x7/8
|
230x3x22.2
|
100
|
24.5
|
24
|
39x24x24
|
5950R.P.M
|
6640R.P.M
|
|
lcme38270615
|
9x1/4x7/8
|
230x6x22.2
|
50
|
25
|
24.5
|
39x24x24
|
5950R.P.M
|
6640R.P.M
|
|
